A blue screen indicates there is no video signal on that channel:
The wires provide a looped circuit via the Truck & Trailer connectors VSP-47B/VSP-57B. This is generally used to control a camera switcher (VCS-020) to allow automatic selection of a trailer camera when the trailer is connected.
Please refer to the drawing of the VSK-50E here.
